Wire to Wire ConnectorsPitch_4.25015H/5016H
  5015H/5016H
Wire to Wire Connectors - Pitch_4.2 : 5015H/5016H
Model Properties PDF
5015 Terminal
5016 Terminal
5015H Plug Housings
5016H Receptacle Housings
5015H/5016H
Specifications
Current rating : 6~7A AC,DC
Voltage rating : 250V AC,DC
Temperature range : -25°C to +85°C
(including temperature rise)
Contact resistance : Initial value/10mΩ Max.
After environmental testing/20mΩ Max.
Insulation resistance : 500MΩ MIN.
Withstanding voltage : 1500V AC/minute
Applicable wire : AWG#18-24
Product Approvals
UL CSA
